Single Zone Maximum Output Power: 50W per channel, 2 channels at 8 ohms
(0.1% THD+N; f=1 kHz) 80W per channel,
2 channels at 4 ohms
140W at 8 ohms, 2 channels bridged
All Zones Continuous Output Power: 35W per channel, 12 channels at 8 ohms
50W per channel, 12 channels at 4 ohms
100W at 8 ohms, each zone bridged
Distortion THD+N 100dB
Frequency Response: 20Hz to 20KHz +/- 0.3dB
Input Sensitivity: 70mV for 1W at 8 ohms
500mV for 50W at 8 ohms
Input Impedance: 47kohms Line Input
Voltage Gain: 32dB
Delay Time: 0.5 to 4.5 minutes
Input Trigger: 12VDC 10 kohms
Output Trigger: 12VDC 100 mA
Power Requirements: North American Model:
100-120VAC 60Hz 1000W
IEC 320 type connector with 3 terminal
detachable power cord.
Fuse Rating: T10AL 250V
Power Requirements: European Model:
220-240VAC 50Hz 1000W
IEC 320 type connector with 3 terminal
detachable power cord.
Fuse Rating: T5AL 250V
Standby Power: < 0.5 W
Dimensions: 17" W x 16.5"D x 5.875"H (43 x 42 x 15 cm)
Weight: 35.05 lbs. (15.77 kg)
